Knitted Wire EMI Shielding Mesh Gaskets Screen Copper Mesh Rf Shielding Gasket

Knitted Wire EMI Shielding Mesh Gaskets Screen Copper Mesh Rf Shielding Gasket

  • Highlight

    knitted wire mesh emi shielding gasket

    ,

    Copper Mesh Rf Shielding

    ,

    emi shielding screen

  • Material
    Galvanized Steel Wire, Tin-plated Copper-clad Steel
  • Type
    EMI Shielding
  • Weave Style
    Dutch Weave
  • Technique
    Perforated
  • Wire Mesh Layer
    Single Or Double Layer
  • Configuration
    Round Or Rectangular
  • Internal Material
    Rubber/sponge
  • Product Size
    Customized Accepted
  • Wire Diameter
    0.5-8mm
  • Selling Units
    Single Item
  • Single Package Size
    10X10X140 Cm
  • Single Gross Weight
    1.000 Kg
  • Package Type
    Carton
  • Place of Origin
    Jiangsu, China
  • Brand Name
    HZ
  • Certification
    CE RoHS
  • Model Number
    wire mesh
  • Minimum Order Quantity
    1 Meter
  • Price
    $1.50 / Meter

Knitted Wire EMI Shielding Mesh Gaskets Screen Copper Mesh Rf Shielding Gasket

EMI EMC RF shielded wire mesh gasket





For strict demands on shielding effectiveness and visual transparency in display windows, shielding meshes were developed that display absolutely uniform black coloration and high damping values. An array of wire meshes made of copper or bronze are available for shielding electromagnetic waves in rooms and non-optical systems.

For applications in the field of shielding technology, we produce special meshes for optical applications, wire mesh for installation in composite materials or other material systems, as well as metal meshes for use in the construction industry.

  1. Brass wire:  copper 65%,zinc35%
  2. Purple copper wire: copper  99.8%
  3. Phosphorus copper wire :copper 85%-90%,tin 5%-15%
Product Features
All mesh gasket’s cross section are rectangular, round,round with tail and double round with tail.
Materials are available intin-plated phosphor
bronze (Sn/Ph/Bz), tin-plated copper-clad steel (Sn/Cu/Fe), silver-plated brass (Ag/Brass), Monel, and aluminum(Al).
Elastomeric core has various function(anti-chemistry, thermal resistance and water proof) for elasticity.
Selection shape
Solid Round Type
Solid Rectangular Type
Hollow Round Type
Solid Round with Fin Type
Hollow Round with Fin Type



  Mesh/inch Wire dia(mm/inch) Aperture(mm)





Stainless steel wire mesh

100 0.089/0.0035 0.17
110 0.1060/0.0040 0.1295
120 0.0904/0.0037 0.1168
150 0.0660/0.0026 0.1041
160 0.0635/0.0025 0.0965
180 0.0584/0.0023 0.0838
200 0.0533/0.0021

0.737





Production range:

  • Width: Standard 1M, Special requirement is accepted.
  • Length:30M/roll
  • Size:Standard 60/100/150 mesh/inch
  • Faraday cage shielding stainless steel wire mesh

Product Description

 • Material: SUS302,201, 304, 304L, 316, 316L, 310, 310S etc

 • Weave: plain, twill, dutch

 • Mesh: 1-2800 mesh

 • Application:  EMI/RFI shielding, Faraday cages, RF window,

 • Specification list for faraday cage shielding stainless steel wire mesh
