380VAC 100A output emi filter for 45KW frequency inverter
80A EMI power line filter in dual-stage configuration, is widely used in the printing equipment, packaging equipment, textile equipment, industrial air conditioners, UPS, motors, servo systems, communication equipment, variable frequency device, electric drives, etc.
FN258 EMI Filter for Three-Phase Inverters and Power Drive Systems
General Purpose EMI Filter for Three-Phase Applications
| AC/DC | AC |
| Nominal Current Range (A) | 80 |
| Nominal Voltage range (V) | 440/220 |
| Operating frequency | 50/60Hz |
| Phase | 3 Phase |
| Configuration | 2 Stage | |
| Rated Current @ 40℃ | 80A | |
| Rated Voltage | 380vAC | |
| Operating Frequency | 50/60Hz | |
| Phase | Three Phase Three Wire | |
| Leakage Current (250VAC 50Hz @ 20℃) | ≤6.0mA | |
| Filter Range | 150KHz-30MHz | |
| Hipot Rating (one minute) | Line to Line: 2250V DC 3S Line to Ground: 2700V DC 3S |
|
| Climatic Category | 25/085/21 | |
| Working Tempearte | -25°C~+85°C | |
| Output Termainal | Threaded stud | |
| Weight | 3.5kg | |
| Dimension | See below | |
Three phase EMC/EMI filters Application:
1. Inverter systems, PV (photovoltaic power system ), Wind power,
2. Industrial frequency converters and motor drives, machine tools,
3. UPS, SMPS
4. and other general purpose power equipment ,medical versions also available.
We are a professional and famous EMI filter manufacturer.
Our technical team has more than 10 years’ experience in designing EMI filter. We know UL VDE CSA CE CQC etc safety standard very well.
Our technical service team learn many kinds of test standard such as industrial application (IEC61800-3 for frequency inverter drive EN12015 for elevator EN55011 for ISM device etc) and military application (GJB151A GJB152A etc).We can solve EMI problem quickly effectively and low-costly.
Our test equipment: LCR digital bridge/voltage proof tester/insulation resistance tester/spectrum analyzer/inductor tester/standard signal source/shield room/interference intensity tester etc
Our product: EMI filter for general purpose/EMI filter for frequency inverter/EMI filter for shielding facility/EMI filter for military application.
Our advantage: high quality/high cost-effective/short lead time
Our service: all products have two years guarantee
Our main customers: frequency inverter drive and servo drive system/MRI shielding system/solar inverter system/rail transit system etc
Our products are sold all over the world, you can rest assured.
