Elastic Emi Shielding Fabric Foam Emi Gasket
Foam gasket with conductive adhesive tape
Electromagnetic shielding is the practice of reducing the electromagnetic field in a space by blocking the field with barriers made of conductive or magnetic materials. Shielding is typically applied to enclosures to isolate electrical devices from their surroundings, and to cables to isolate wires from the environment through which the cable runs. Electromagnetic shielding that blocks radio frequency electromagnetic radiation is also known as RF shielding.
Product features for foam gasket with conductive adhesive tape
1. Compact conductive fibers, no sharp edges
2. Good elasticity and consistency
3. Conductive adhesive
4. Low surface contact resistance
5. Shielding performance will not reduce after 10,000 times friction
6. Thin section suitable for I/O and D- subminiature lining
7. Could be used to ground connection
Specification for foam gasket with conductive adhesive tape
| Name | foam gasket with conductive tape |
| Shielding effectiveness | 60-80dB/30MHz-1GHz |
| Surface resistance | <0.07ohms/sq inch |
| Permanent deformation | < 10% |
| Temperature range | -10~110°c |
| Flammability | UL 94(HF-1) |
| Compression | 30-50% |
Application for foam gasket with conductive adhesive tape Widely used in electronic box,case,interior chassis, industrial equipment, notebook PC, mobile communication devices,medical equipment, RF door and MRI door etc.
Type for foam gasket with conductive adhesive tape
Other information for conductive foam gasket with adhesive
| Foam gasket | |
| MOQ | 50M |
| Delivery time | 5-7days |
| Payment Terms | T/T, Paypal, Western Union |
| Longest dimension cut | 1.22m/pcs |
| Place of region | China |
Our products are sold all over the world, you can rest assured.
