Power Line 3 Phase Passive Solar Inverter Emi Filter for PV Inverters 440 480VAC 5A

Power Line 3 Phase Passive Solar Inverter Emi Filter for PV Inverters 440 480VAC 5A

  • High Light

    passive emi filter

    ,

    3 Phase Inverter Emi Filter

    ,

    EMC EMI Filter for PV Inverters

  • Type
    EMI Filter
  • Transfer Function
    Low Pass
  • Nominal Center Frequency
    50/60Hz
  • 3dB Bandwidth
    14K
  • Insertion Loss
    100dB
  • Input Impedance
    50ohm
  • Stopband Attenuation
    100dB
  • Rated Voltage
    380VAC
  • Rated Current
    40A
  • Operating Frequency
    50/60Hz
  • Application
    POWER SUPPLY
  • Port
    Shanghai
  • Place of Origin
    China
  • Brand Name
    nenglv
  • Certification
    CE RoHS
  • Model Number
    HZ-40INF
  • Minimum Order Quantity
    >=1 Pieces
  • Price
    $50.00
  • Packaging Details
    10 pcs in one carton the gross weight is about 10Kg
  • Supply Ability
    100 Piece/Pieces per Week

Power Line 3 Phase Passive Solar Inverter Emi Filter for PV Inverters 440 480VAC 5A

RF Filter Passive Filter Power Three Phase Output Inverter Filter 440/480VAC 5A


How to measure filter effectiveness

(1) Insertion loss

The noise reduction effect of a filter is represented by insertion loss. As shown in Fig. 3, a filter was inserted into a circuit connecting a 50 ohms signal source with a load, and then the change in voltage on the load side (B to C) was measured. This is normally expressed in dB.

(2) dB

dB (decibel) is a unit used to express a ratio. As shown in Table 2, the ability to reduce noise to 1/10th is expressed as 20dB, while the ability to reduce noise to 1/100th is expressed as 40dB. Each time noise drops to 1/10th, the dB increases by 20 (for insertion loss).
Using dB is very convenient as it can express a large ratio through addition. The result of measuring noise is also normally expressed in dB. For example, 40dBµV represents a voltage where 1µV is 0 dB, and so it means 100µV.

(3) Numbers to keep in mind

When noise doubles, the dB changes by 6dB. When noise increases tenfold, the dB changes by 20dB. These two numbers are used very often, so it can be useful to keep them in mind.
Note however that these numbers are used when representing voltage. For power, a tenfold increase results in a change of 10dB. This is because power has a relationship proportional to voltage squared (P=V2/R).

(4) S-parameter substitution

When a filter can be regarded as a linear circuit, insertion loss can be substituted by the absolute value of the S-parameter transmission coefficient (S21 or S12) measured on a 50 ohms system. This is because a 50 ohms measurement system is connected before and after the filter, for both measurements. Whenever possible, we use the value measured with the S-parameter as the insertion loss.



Parameter Value
Rated Voltage, RMS 110...250V
Rated Current, RMS 3A
Transient Signal Attenuation (Typical)
Differential Mode 24dB
Common Mode 20dB
Leakage Current
Standard models <3.5mA
Medical version <0.5mA
Power Indication LED
Dimensions (WxDxH) 80mmx47mmx127mm
Available in a range of input / output configurations
