Low Pass 16A 230vac 50Hz EMI Power Line Filter Ac Current Rfi Noise Filter Suppression

Other Videos
March 21, 2025
Category Connection: EMI Power Line Filter
Chat Now Contact Us
Tags:
#emi rfi ac power line filters #signal emi filter #Emi Filter 5A
Brief: Discover the Low Pass 16A 230VAC 50Hz EMI Power Line Filter, designed to suppress RFI noise and ensure electromagnetic compatibility. Ideal for various equipment, this filter meets global compliance standards and optimizes device performance with correct installation.
Related Product Features:
  • Rated voltage of 250VAC and current of 30A for robust performance.
  • Operational frequency of 50/60Hz ensures compatibility with standard power systems.
  • Minimal voltage drop of less than 1V for efficient power delivery.
  • Withstands 140% of rated current for 15 minutes, ensuring durability.
  • Low harmonic distortion of less than 2% at full rated current.
  • Leakage current ≤0.2A@380/230VAC and 50Hz for safety.
  • High dielectric withstanding voltage of 1000VDC (line to line and line to case).
  • Insertion loss ≥100dB@14K-40GHz for superior noise suppression.
Faqs:
  • What is the purpose of the EMI Power Line Filter?
    The EMI Power Line Filter suppresses electromagnetic interference (EMI) and radio frequency interference (RFI), ensuring devices function correctly and comply with global regulations.
  • How do I ensure optimal performance of the EMI filter?
    Follow best practices for installation, including proper grounding, to minimize crosstalk, emissions, and susceptibility, ensuring safe compliance margins.
  • What are the key specifications of this EMI filter?
    Key specifications include a rated voltage of 250VAC, current of 30A, operational frequency of 50/60Hz, and insertion loss ≥100dB@14K-40GHz.
